SYSTEM PROCESSOR TUNINGS
The following table includes the tunings for the dbx DriveRack 260. It is always a good idea to check for the
latest tunings on the JBL Pro web site at http://www.jblpro.com/pages/tunings/tunings_main.htm. If you have a
processor for which VRX tunings are not developed, the following table can serve as a starting point for setting
your processor.
Note to DriveRack PA users: The DriveRack PA does not include a POLARITY function. When using the
DriveRack PA for a tuning that requires the polarity parameter to be set to “INVERT” it will be necessary to
invert polarity at the amplifier output cable connection or by using a specially wired cable or adapter between
the processor and the amplifier channel.
dbx DriveRack 260
Speaker Model(s):
V
RX932LA
Revision Date:
03/02/05
bi-amp full range: 1x VRX932LA 2x VRX932LA 3-6x VRX932LA xover for Sub
M
ID HIGH MID HIGH MID HIGH LOW MID
I
nput Source A A A A A A A A
COMP/LIMIT
Output Gain 0dB -15 dB 0.0dB -5.5dB 0.0dB -5.5dB 2.0 dB 0dB
O
utput Limit
DELAY & POLARITY
O
utput Delay 0.0ms 0.25ms 0.0ms .25ms 0.0ms .25ms 0.0 ms 0.0 ms
Output Delay Link
Polarity NORMAL INVERT NORMAL INVERT NORMAL INVERT NORMAL NORMAL
XOVER
Output Lo Shape BUT18 LR24 BUT18 LR24 BUT18 LR24 BUT18 LR48
Output Lo Frequency 46.8 Hz 1.09 KHz 46.8Hz 1.091kHz 46.8Hz 1.091kHz 31.3 Hz 81.1Hz
Output Hi Shape LR48 BUT6 LR48 LR48 BW6 LR48 BUT6
Output Hi Frequency 1.41KHz OUT 1.414kHz OUT 1.414kHz OUT 81.1Hz OUT
EQ
Output EQ1 Type BELL BELL BELL BELL BELL BELL BELL
Output EQ1 Frequency 630 Hz 3.89 KHz 648Hz 2.83kHz 648Hz 2.83kHz 68 Hz
Output EQ1 +/- -2.5 dB -6dB -3.0dB -12.0dB -3.0dB -12.0dB 2 dB
Output EQ1 Bandwidth 3.4 Q 1.38 Q 2.996Q 1.215Q 2.996Q 1.215Q Q: 5
Output EQ2 Type BELL LO SHELF BELL BELL BELL BELL
Output EQ2 Frequency 2.31 KHz 136Hz 16.0kHz 841Hz 13.1kHz 41.7 Hz
Output EQ2 +/- -4.5 dB 5.0dB 5.0dB 2.5dB 5.0dB 1.5 dB
Output EQ2 Bandwidth 2.63 Q
Slope 4.5dB/Oc
t
2.315Q 2.996Q 2.315Q Q: 5
Output EQ3Type BELL BELL BELL
Output EQ3 Frequency 1.00 KHz 1.73kHZ 1.73kHZ
Output EQ3 +/- -12.0 dB -3.0dB -3.0dB
Output EQ3 Bandwidth 7.38 Q
2.996Q 2.996Q
Output EQ4 Type HI SHELF BELL BELL
Output EQ4 Frequency 12.3 KHz 1.0kHz 1.0kHz
Output EQ4 +/- 8.0dB -9.0dB -9.0dB
Output EQ4 Bandwidth 9.0dB slope 12.364Q 12.364Q
> using equal gain amplifiers <
NOTE:
For VRX932LA systems in passive mode use the suggested Xover For Sub filter as is and adjust the subwoofer gain for desired performance.
For VRX932LA systems in bi-amp mode use the suggested Xover For Sub filter settings and implement it to your matching bi-amp fullrange table.
