Introduction .................................................... 15-41
Remove and Install ....................................... 15-42
Introduction
The bedplate acts as the main strength component
of the engine. it maintains the correct alignment and
supports the weight of the internal components.
Figure 122.
1
2
1 Bedplate
2 Crankcase
