Lubrication points
Fig 28
Pivot Pins –
Dumper Skip Lift Arm and Carriage Pivots
Fig 29
Fig 30
Pivot Pins –
Dumper Skip Ram Pivot
Articulated Joint
A Dumper body ram pivots
A Grease nipples
A Dumper body lift arm points
B Carriage pivots
