6 Please see operator manual for full details.
Top 5 safety tips
Activity/Risk Advice
Driving
Ensure the dumper body is lowered during travel, particularly if driving
on a slope. It is recommended to travel to a tipping point with the skip
down before lifting/tipping.
Stopping
Ensure the direction control stalk is left centrally in the neutral position
with the park brake rocker switch engaged when the machine is not
required to travel. Do not leave the machine parked on a slope/gradient
over 25% (14 degrees).
Loading
Do not load above the max fill line, parallel with the top of the skip.
This could impede visibility and cause the machine to become unstable.
The operator should dismount and stand clear of the machine while
being loaded.
