jcb 215 Service Manual

1 - 2
Serial Plates
A Front Axle (2WS machine)
B Front Axle (4WS machine)
C Rear Axle (2WS machine)
D Rear Axle (4WS machine)
E Synchro Shuttle Transmission
F Powershift Transmission
G Engine
Section 1 General Information
9803/3280
Section 1
1 - 2
Issue 1
E
F
G
A
S257580
A401030
S260120
B
C
S259100
S156571
S259110
D
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
