jcb 215 Service Manual

Steering
9803/3280 Issue 1
Steer Unit Operation
- 4 Wheel Steer Machines
4 Wheel Steer Mode
- Right Turn, Unassisted
The illustration shows the circuit operation with the
engine stopped. Turning the steering wheel rotates
the inner spool A until the cross pin engages with
and rotates outer sleeve B, metering oil to the
stator D, and pumping it out to power track rod
rams 40 and 41 under manual pressure only.
As there is no supply from the pump, oil from one
side of the power track rod rams, supplemented by
exhaust oil if necessary, is used to feed the other
side via non-return valve F.
Component Key:
A Inner Spool
B Outer Spool
D Stator
F Non-Return Valve
X Steer Mode Control Valve
40 Front Power Track Rod Ram
41 Rear Power Track Rod Ram
4 - 9 4 - 9
Circuit Descriptions
Section H Section H
www.WorkshopManuals.co.uk
Purchased from www.WorkshopManuals.co.uk

jcb 215 Specifications

General

Engine Power	74 hp
Rated Operating Capacity	2, 100 lbs
Lift Path	Vertical
Tipping Load	4, 200 lbs
Net Engine Power	74 hp
Width over Tires	1, 800 mm
Height to Top of Cab	2, 300 mm
Hinge Pin Height	2, 800 mm
Travel Speed	11 km/h
Travel Speed (High)	11 km/h
