jcb 3CX Compact User Manual

Introduction
About this Manual
2 9831/1400-11 2
Location of Manual
For: 3CX Compact, Cab ............................................................................................................. Page 2
For: 3CX Compact, Fixed Canopy ............................................................................................. Page 2
(For: 3CX Compact, Cab)
The manual is located in the case attached to the back of the seat. The manual should always be returned
to its case after use.
Figure 2.
A
A Manual location
(For: 3CX Compact, Fixed Canopy)
The manual is located in the case attached to the canopy roof. The manual should always be returned to its
case after use.
Figure 3.
A
A Manual location

jcb 3CX Compact Specifications

General

Engine Power	55 kW
Travel Speed	40 km/h
Maximum Loader Capacity	1, 800 kg
Engine Model	JCB Diesel by Kohler
Loader Bucket Capacity	0.6 m3
