jcb 3CX Compact - Main Component Locations

About the Product
Description
9 9831/1400-11 9
Main Component Locations
Figure 5.
A
C
D
G
H
F
B
J
K
E
A Dipper B Boom
C Shovel D ROPS (Roll-Over Protective Structure)/FOPS
(Falling Object Protective Structure) cab or
canopy
E Bucket F Hydraulic oil tank
G Loader arm H Fuel tank
J Stabilisers K Kingpost
