Description
9 9821/7050-4 9
Main Component Locations
Figure 3.
A
A
B
C
D
F
G
L
E
H
J
K
A Loader arms
B Quickhitch
C ROPS (Roll-Over Protective Structure)/FOPS (Falling Object Protective Structure) Cab
