Section 1-5 - General Information
Service Tools
Tool Detail Reference
1-5-12 1-5-12
9803/3750-05 (1-06-00)
Note: No longer available, refer to 998/11046 JCB
ServiceMaster Flow Test Kit. K
Fig 28. ( T 1-5-12).
892/00268 Flow Monitoring Unit
Fig 27. Flow Test Equipment
892/00269 Sensor Head 0 - 100 l/min (0 - 22 UK gal/min)
892/00273 Sensor Head 0 - 380 l/min (0 - 85.5 UK gal/min)
892/00293 Connector Pipe
892/00270 Load Valve
1406/0021 Bonded Washer
1604/0006A Adapter 3/4 in M x 3/4 in M BSP
1612/2054 Adapter 3/4 in F x 3/4 in M BSP
892/00271 Adapter 3/4 in F x 5/8 in M BSP
892/00272 Adapter 5/8 in F x 3/4 in M BSP
816/20008 Adapter 3/4 in F x 1/2 in M BSP
892/00275 Adapter 1/2 in F x 3/4 in M BSP
892/00276 Adapter 3/4 in F x 3/8 in M BSP
892/00277 Adapter 3/8 in F x 3/4 in M BSP
1606/0015 Adapter 1.1/4 in M BSP x 1 in M BSP
892/00078 Connector 1 in F x 1 in F BSP
1604/0008 Adapter 1 in M x 1 in M BSP
1606/0012 Adapter 1 in M x 3/4 in M BSP
816/20013 Adapter 3/4 in F x 1 in M BSP
Fig 28. 998/11046 JCB ServiceMaster Flow Test Kit
998/11047 600 LPM Flow Turbine with Loading Valve
998/11048 1-7/8" UNF x1 - 1/4" BSP Flow Block Adaptors
x2
998/11049 Carrying Case for Flow Test Kit
998/11050 Temperature Sensor (125°C Max)
