8008 CTS, 8010 CTS 17
Service & Access Covers
Fig 16
Engine Cover
Please note; if the operator’s seat is positioned too far forward it can foul the control
levers when the engine cover is fully raised.
Always stop the engine and operate the controls to relieve hydraulic pressure before raising the
engine cover.
Always adjust and latch the seat fully to the rear before raising the engine cover. Make sure that you
return the seat to your correct operating position before operating the machine.
The engine cover allows access to all key components on the Micro machines.
