65R-1, 67C-1, 85Z-1, 86C-1, 90Z-1, 100C-1 19
Service/Maintenance Points: 65R-1 / 67C-1
A Fuel filter
B Hydraulic oil level indicator
C Fuel filler cap
D Refuelling pump
E Hydraulic oil filler cap
Fig 14
A Air filter
B Coolant expansion bottle
C Battery
D Battery isolator
E Radiator
F Washer bottle
G Engine oil dipstick
H Engine fuel filter
Fig 15
R Track gearbox
S Track tensioner
Fig 16
