14
Please see operator manual for full details.
1 2 3
4 65
7
Connect Isolator
Trigger & Joystick
Pull E-Stops Switch Key Right
Cradle Release
Mode Select
Operate Machine
The isolator is located within
the battery tray on the left
hand side of the machine.
Pull the trigger on the back
of the joystick to enable
operation.
The cradle can be released
from the platform by
removing the bolt.
If CH is shown on the platform
controller, the key switch is in
the wrong position. The switch
must be on platform controls
to use them. The machine will
not operate whilst charging.
Choose from either lift/
lower or drive mode. Do not
attempt to operate prior to
charge status being shown.
Ensure both the ground
controls and platform controls
E-stops are released.
Turn the key switch right to
enable the platform controls.
Operating from the Platform
To Next Page
