jcb CT160 - Performance Dimensions; General

Technical Data
Performance Dimensions
131 9831/7750-1 131
Performance Dimensions
General
For: CT160 ............................................................................................................................. Page 131
For: CT260 ............................................................................................................................. Page 131
(For: CT160)
Table 18.
Description CT160-80 CT160-100
Steering angle 33 ° 33 °
Oscillation angle 8 ° 8 °
Inner turning radius 2,160 mm 2,090 mm
Drum offset (standard) 56 mm 56 mm
Travel speed 9 km/h ( 5.6 mph) 9 km/h ( 5.6 mph)
Gradeability with or without vibration 25 –35 % 25 –35 %
Table 19.
Description CT160-80 CT160-100
Vibration stage 1 2 1 2
Vibration frequency 50 Hz 66 Hz 50 Hz 66 Hz
Amplitude 0.47 mm 0.41 mm
Centrifugal force 12.8 kN 22.2 kN 12.8 kN 22.2 kN
(For: CT260)
Table 20.
Description CT260-100 CT260-120
Steering angle 33 ° 33 °
Oscillation angle 8 ° 8 °
Inner turning radius 2,475 mm 2,375 mm
Drum offset (standard) 60 mm 60 mm
Travel speed 10 km/h ( 6.2 mph) 10 km/h ( 6.2 mph)
Gradeability with or without vibration 30 –40 % 30 –40 %
Table 21.
Description CT260-100 CT260-120
Vibration stage 1 2 1 2
Vibration frequency 50 Hz 66 Hz 50 Hz 66 Hz
Amplitude 0.56 mm 0.51 mm
Centrifugal force 23.6 kN 41.1 kN 23.6 kN 41.1 kN
