jcb CT160 - Relays

Technical Data
Electrical System
144 9831/7750-1 144
Fuse No. Circuits Protected Rating
FA6 Beacon 15 A
FA7 Front worklight 5 A
FA8 Vibration 3 A
FA9 MECU (Machine Electronic Control Unit)Ignition 3 A
FA10 Livelink ignition 3 A
FB1 Reverse alarm 3 A
FB2 Hazard 3 A
FB3 Diagnostic/Livelink 5 A
FB4 MECU 20 A
FB5 Spare -
FB6 Horn 5 A
FB7 Rear worklight 15 A
FB8 Front worklight LED (Light Emitting Diode) 7.5 A
FB9 Rear worklight LED 7.5 A
FB10 Livelink 5 A
FC1 Front worklight 15 A
FC2 Spare -
FC3 Power socket 15 A
FC4 Spare -
FC5 Pre-heat 3 A
FC6 ESOS (Engine Shut-Off Solenoid) 25 A
FC7 Glow plug controller 3 A
FC8 Glow plug 40 A
FC9 Glow plug controller 3 A
FC10 Spare -
Relays
