JCB-PW15040P
Instruction & User Manual
13
Feature Descriptions
A – High Pressure Hose – Connected to the lance to move high pressure
water from the Water Pump to the Lance.
B – Fuel Tank
C – High Pressure Lance – The High Pressure Lance uses different
nozzles to expel water in different patterns.
D – Engine Carburettor Controls – These Control engine fuelling.
E – Wheels – Used to transport the machine.
F – Front Feet – The machines uses these as rests when stationary
G – High Pressure Pump – This house the water inlet and high pressure
outlet.
H – High Pressure Nozzles – Varying nozzles that provide 0°, 15°, 25°,
40° spray patterns
