JCB-PW15040P
Instruction & User Manual
27
Maintenance – Sediment Filter
> Move the fuel valve to the OFF position, then remove the fuel sediment cup by twisting off. Also remove the
O-ring.
> Wash the sediment cup and O-ring in non-flammable solvent, and dry them thoroughly.
> Place the O-ring in the fuel valve, and install the sediment cup. Tighten the sediment cup securely.
> Move the fuel valve to the ON position, and check for leaks. Replace the O-ring if there is any leakage.
Fuel Valve Lever
O-Ring
Sediment Cup
Drain Bolt
Washer/Gasket
