27 - Driveline
06 - Semi-Automatic Gearbox
13 - Clutch - Master
27 - 138 9813/6850-2 27 - 138
Table 245.
Item Description
A Lubrication nozzles
B Bolts
C Springs
D Spring pillars
E Oil baffle plate
F Pressure plate
G Piston
H Drum
J Outer seal
K Socket head capscrews
(x8)
L Hub
M O-ring 1
N Circlip
P Blanking disc
Q Inner bearing
R O-ring 2
S Sealing ring
Item Description
T Inner piston seal
U Outer bearing
V Bronze bush
W M8 bolt (x2)
X Dowel 1
Y Dowel 2
Z Jacking bolts (x2)
Assembly
Assembly is the opposite of the disassembly
procedure but additionally follow the steps below.
1. Check that the oil feed slots and drillings are
clear.
2. Check the condition of the pressure plate, if it is
excessively scored then replace with a new one.
3. If it is necessary to replace the pressure plate,
dowel 1 and dowel 2 must be installed to the plate
before assembly.
