JCM WBA-SS Series User Manual

14. Error Code
Error Code Table 1
Error Code Table 1 summarizes the error codes of the receiving operations of the
transfer unit/acceptor headpiece and the unit with cash box.
No. of indicator
LED flashes
1
2
3
4
5
6
7
8
9
10
11
12
Description
Cash box full
Stacker jam, or pusher unit problem.
Transport cover is open, or stacker lever problem.
Jam in the acceptor head.
The acceptor head is detached or it has been calibrated, or wrong acceptor
head type.
Transport motor problem. The pulse signal is not sent from the encoder sesor.
Reserved.
Stacker lever problem.
Reserved.
Reserved.
Reserved.
No cash box.
Error Code Table 2
Acceptor head and stacker test.
No. of indicator
LED flashes
1
2
3
4
5
6
7
Description
Reserved.
Stacker lever problem.
Jam in the acceptor head.
Cash box jam.
Cash box full.
Pusher mechanism problem.
The acceptor head is detached or it has not been calibrated, or wrong
acceptor head type
Modelnumbers
Specifications
Operation Manual
Communication
Specifications
Disassembly
Assembly
Wiring Diagram Trouble Shooting
Calibration
Software Download
Parts List
