Jeanneau 64 - Page 34

- 34 -
Layout diagram -
Electric winch
1. Winch
2. Engine
3. Operation relay
4. Load controller
5. Waterproof switches
6. Fuse
7. Breaker
8. Service battery
- Refer to the manufacturer's instructions for use and maintenance.
- Avoid bulky clothing, long hair and jewellery that might become caught in
the winch when it is moving. Avoid riding turns when using the winches.
