8.2.3 Power distributor
- The electronic charge dividers isolate the battery banks from each other and allow the
charge to be directed automatically to the battery with the lowest charge. They give the
advantage of preventing a drop in voltage.
- The charge divider is electronic. It is designed to distribute the charging current with a low
voltage drop between the battery banks (engine and service batteries). It prevents the current
from circulating from one battery to another. When the voltage of the charger or alternator is
available, the charge divider's green indicator comes on.
8.2.4 Connection of battery set
If the power of the engine battery is low, there is no coupling system between the ancillary
battery sets and the engine battery.
Location:
Power unit - 24V (Saloon)
8
DC INSTALLATION
