Jeep commander 2008 - Page 435

Cav-
ity
Cartridge
Fuse
Mini-Fuse Description
1 30 Amp
Green
Audio Amp (B+)
2 15 Amp
Blue
Sunroof (B+)
3 10 Amp
Red
Htd Mirror (EBL)
4 20 Amp
Yellow
Rr Pwr Out (B+)
5 10 Amp
Red
Rr HVAC (R/O)
(Commander Only)
6 Spare (B+)
7 20 Amp
Yellow
Door Locks (B+)
8 Spare (B+)
9 20 Amp
Yellow
Pwr Outlet (B+)
Cav-
ity
Cartridge
Fuse
Mini-Fuse Description
10 10 Amp
Red
Final Drive Control
Module (FDCM),
Heater Ventilation/
Air Conditioning
(HVAC), Rear Heated
Seat Switch, Transfer
Case Switch, O/H,
Heater Ventilation/
Air Conditioning
(HVAC) Relay, Rear
Park Assist
11 Spare (B+)
12 10 Amp
Red
Door Mods, Mem. Sw,
O/H Lamps, IP Cour-
tesy Lamps, Glove
Box Lamp (B+)
13 10 Amp
Red
Autowipe (R/A)
434 MAINTAINING YOUR VEHICLE
