NOTE: Structural Adhesives used are a high strength epoxy and a high expansion lower strength antiflutter
material. High strength epoxy is used on all areas.
STRUCTURAL ADHESIVE LOCATION INDEX
Back to Index
DESCRIPTION FIGURE
PLENUM ASSEMBLY 1
FRONT FLOOR 2
SIDEMEMBER ASSEMBLY (1 OF 3) 3
SIDEMEMBER ASSEMBLY (2 OF 3) 4
SIDEMEMBER ASSEMBLY (3 OF 3) 5
BODY SIDE APERTURE INNER ASSEMBLY 6
BODY SIDE APERTURE COMPLETE 7
ROOF WITOUT SUNROOF 8
ROOF WITH SUNROOF 9
BODY IN WHITE – COMPLETE (1 OF 2) 10
BODY IN WHITE – COMPLETE (2 OF 2) 11
Preferred Mopar Products:
• Fusor 112B – Part No. 05083855AA
• Dispenser – Part No. 05016570AA
