WELD PROCESS
CAUTION: All welds should conform to Daimler Chrysler vehicle engineering process standard "PS 9472".
GAS METAL (MIG) SHIELDED METAL
WELDING PROCESS *FLUX CORED ARC
ARC ARC (STICK)
Material Thickness 1.80mm to 1.80mm 1.80mm to 1.80mm 1.80mm to 1.80mm 1.80mm to 1.80mm
Lincoln Electric Co.
Electrode Type
Lincoln Electric Product
Product No: NR-211 MP
AWS ER70S-3
AWS E 7018
No. NP-211 MP
(Do not Substitute)
(Do not Substitute)
Electrode Size Inches .035 Tubular .045 Tubular .035 Solid 3/32
Electrode Stick Out 3/8" 3/8" - 1/2" 1/2" - 5/8" N/A
Electrode "–" Electrode "–" Electrode "+" Electrode "+"
Polarity
Work Piece "+" Work Piece "+" Work Piece "–" Work Piece "–"
75% Ar
Shielding Gas Self Shielded Self Shielded
25%CO2
Self Shielded
Gas Flow Rate N/A N/A
25-35 CFH
N/A
Wire Feed Speed 90-110 Vertical 110-130 Vertical Down 245-250 Vertical Down
(inches per min.) 60-70 Flat & Horizontal 70-90 Flat & OH 210-225 Flat & OH
N/A
Approx. Amperage
Vertical Position
110-120 160-170 175 85 (3/32 Dia.)
Flat & Overhead
50-60 120-140 155 90 (3/32 Dia.)
Voltage 15-16 15-18 19-20
Direction of Welding
Vertical Position Vertical Down Hill (only) Vertical Down Hill (only) Vertical Down (only) Vertical - Up (only)
Flat & Overhead Flat - Push or Drag Flat - Push or Drag Flat - Push or Drag Flat - Drag
Position
*First choice—*Flux Cored Arc Welding Process: Butt joints - Vertical position welds - maintain end of electrode wire at leading edge
of weld puddle while traveling down hill to produce maximum penetration into sleeve. This technique works for Gas Metal Arc (MIG) as
well. Note: If MIG welding process is selected the galvannealed coating must be removed from both sides of the material adjacent to
the weld joint.
INNER RAIL TO OUTER RAIL
PM49, MK49 AND MK74
