Jeep Compass
Electrical system
The fusebox has additional ATO fuse holders installed on the
bottom of the box.
Fuel pump F21 15 A
Engine control module power F22 20 petrol
engine
15 diesel engine
Window heater grid F23 30 A
Automatic transmission electronic control unit power supply F24 15 A
12 V battery powered socket in rear luggage compartment F30 20A
Glow plug module F81 60 A
Diesel filter heater F82 40 A
HVAC fan F83 40 A
Four-wheel drive power F84 30 A
Automatic transmission gear selector F87 5 A
Heated door mirrors F88 7.5 A
Heated rear window F89 30 A
IBS sensor (battery charge status) F90 5 A
Battery double control relay Fxx 10 A
Description Fuse Ampere
Transmission control module (4x4/AWD) F1 5 A beige
ECM - Start diagnostic detection F2 10 A red
Steering control module F3 2 A grey
Description Fuse Ampere
