1. Service
1-1. Temperature
Classification Symptom Service Factor
Temperature Temp doesn’t increase Heater Malfunction
Check point
1. After setting 100℃ then press Start Button to operate the unit.
2. Check the Heater temp itself. (Be careful heater is very hot.)
3. Measure resistance checking positive terminal of heater using of the multi meter.
Æ If resistance doesn’t measure, it is a malfunction
Solution
- Replace a heater.
1. “2-1-8. Heater disassembly” Reference
(When replacing a Heater, Inner Chamber Jacket, Chamber Disassembly are very complicated, Do not replace the heater in the field.)
2. The assembly is reverse order of disjointing.(Heater should be checked resistance for inferiority.)
Classification Symptom Service Factor
Temperature Temp doesn’t increase Relay Malfunction
Check point
1. 1. Press the Start Button to operate the unit, Measure Voltage of Output terminal using of the
multi meter.
Æ If Voltage doesn’t measure, it is a malfunction
Solution - Replace the Relay.
To Next Page
