Technical Data
Woodchipper
Max. wood diameter cm 15
Chipping length mm 5-20
Hydraulic oil reservoir capacity l 26
Length mm 1900
Width mm 700
Height 2310
Weight kg 1200
Oil flow rate max. L/m 20
Diesel Engine
Type Kubota D-1703
Power KW/HP 27,5 / 37,3
Rpm 3000
Motor nr. 05Q1510
Track undercarriage
PT 15 G
(Standard)
PT 15 G All
(Variable)
Length mm 1420 1420
Width mm 980 780-1160
Distance between center mm 1070 1070
Height cross member 280 287
Track width mm 230 230
Track height mm 350 350
Roller 3+3 3+3
Dynamic capacity kg 1500 1500
Static capacity kg 1750 1750
Weight kg 310 395
Motor displacement cc. 100 100
Transmission ratio. 1:6 1:6
Pressure max. bar 160 160
Oil flow rate max. L/m 60 60
Max gradeability 60% 60%
Speed km/h 5,2 5,2
Ground pressure kg/cmq 0,35 0,36
