PREPARATION FOR USE
Installing the JAS-725 under a cabinet
1. Make the position of the 3 holes by using the supplied template. Use a drill to make the
holes.
2. When the cabinet door overhangs the shelf and obstructs the unit, you can adjust the
unit/shelf height.
3. Install the unit with the supplied mounting kit.
Unpack the unit carefully to remove all the accessories from the packing. Verify that the
following accessories are present before setting up the unit.
Main Unit X 1
AC adaptor X 1
User Manual X 1
Mounting kit X 1
LOCATION OF CONTROLS
MAIN UNIT
LIGHT
DC 5V
LINE IN
1
2
3
4
5
6
22
7
8
11
13
9
REAR VIEW
FRONT VIEW
14
18 1819 2021 21
12
15 17
11
To Next Page
