E-6
LOCATION OF CONTROLS
MAIN UNIT
1. POWER ON/STANDBY BUTTON /
STANDBY MODE INDICATOR
11. VOLUME CONTROL KNOB
2. FUNCTION MODE BUTTON 12. LCD DISPLAY
3. TIME SET/MEMORY BUTTON 13. CD DOOR OPEN/CLOSE BUTTON
4. TUNER PRESET- BUTTON
14. NFC LINKING POINT
5. AUX IN JACK 15. FM WIRE ANTENNA
6. TUNER PRESET+ BUTTON 16. HEADPHONE JACK
7. CD STOP BUTTON/
BLUETOOTH PAIR BUTTON
17. RIGHT SPEAKER CONNECTOR
8. CD/BLUETOOTH PLAY/PAUSE /
18. LEFT SPEAKER CONNECTOR
9. CD/BLUETOOTH SKIP PREVIOUS /
TUNE- BUTTON
19. AC POWER CORD
10. CD/BLUETOOTH SKIP NEXT /
TUNE+ BUTTON
20. BATTERY DOOR
To Next Page
