5
MS30BT
W
iring Dia
gr
am
WIRE COLOR
DESCRIPTION
PURPLE
RIGHT REAR SPEAKER (+)
PURPLE/BLACK
RIGHT REAR SPEAKER (
)
GRA
Y
RIGHT FRONT SPEAKER (+)
GRA
Y/BLACK
RIGHT FRONT SPEAKER (
)
WHITE
LEFT FRONT SPEAKER (+)
WHITE/BLACK
LEFT FRONT SPEAKER (
)
GREEN
LEFT REAR SPEAKER (+)
GREEN/BLACK
LEFT REAR SPEAKER (
)
RED
ACC +12V
BLACK
GROUND
Note: Do not connec
t the red
wire to a
constant power
connection. T
he red wire
should be co
nnected to a
vehicl
e connection
with switched power
such as IGN
or
ACC.
