Black DIN Cable - SiriusXM
Black Female 3.5mm - BT Microphone
Black 1mm Wire - BT Antenna
Black - HDMI
Wiring Diagram
CAUTION! IMPORTANT: Incorrect wiring connections can damage the unit. Follow the wiring instructions
carefully, or have the installation handled by an experienced technician.
Need Help? For technical assistance, call the Jensen customer support line at 1-888-921-4088.
Note: Some vehicles may not support all SWC functions. Professional Installation is recommended.
RIGHT FRONT SPEAKER (-)
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
BATTERY 12V (+)
GROUND (-)
ACC / IGNITION (+)
TFT DIMMER (+)
POWER ANTENNA / AMP (+)
PARKING BRAKE (-)
REVERSE (+)
LEFT FRONT SPEAKER (+)
BLACK
YELLOW
RED
PINK
GREEN/WHITE
BLUE
GRAY/BLACK
GRAY
GREEN/BLACK
GREEN
PURPLE/BLACK
ORANGE
PURPLE
SWC Interface
WHITE/BLACK
WHITE
LEFT FRONT SPEAKER (-)
RIGHT FRONT SPEAKER (+)
Yellow RCA - Rear Camera In
To Next Page
