2. Roll
Raise the rollback handle and the deck will slide back. Roll the deck
rearward approximately 12 inches to clear the mechanical hold downs at
the front of the frame. A decal is provided on the rubrail to aid in
determining the amount to roll. Align the decal pointer with the red control •
handle.
~ 2
I .••.•.
Q-Ag:j;
4. Roll
Raise the roll handle and the deck will slide back. Continue this operal/on
until the approach plate of the deck has contacted the ground.
Make sure that the rear bumper and the approach plate are both In firm
contact with the ground before loading. There should be an equal weight
dislribul/on between the rear bumper and the end of the deck.
4
Q
"~J •••••
Rev. _
•
•
2.1
Date _
