Jet-tech F18 - Base Component Location; Component Identification

Base component location
F-18
May 2004
16
View from under of the dishwasher
40229
DRAIN PUMP
20569
WATER
SOLENOID
VALVE
40240
WASH PUMP
20199
RINSE-AID
PUMP
10349 (F18-DP)
10351 (F18)
DRAIN CONNECTION
20588
DETERGENT PUMP
20582
TERMINAL BLOCK
60137
Drain Plug
60004
Gasket
FRONT
15019
BOTTOM HUB
WASH-ARM SUPPORT
15689
BOOSTER TANK
RINSE WATER
