1
DISHWASHER MANUAL
For operator. Do not discard.
2019 03
F-14
F-16DP
F-18DP
F-22
INSTALLATION AND MAINTENANCE
JET TECH DISHWASHER OPERATOR MANUAL 2018 english only
1 mars 2019 07:06:50

Table of Contents

Questions and Answers

  • D
    debra21Aug 14, 2025
    What to do if my Jet-tech Dishwasher overflows?
    • A
      Ana YoungAug 14, 2025
      If your warewasher is overflowing, the drain outlet hose may be kinked or blocked; straighten or unblock it. Also, the drain pump might be blocked or defective; call for service to address this issue, keeping in mind that blockages due to food or debris are not covered under warranty. High incoming water pressure could also be the cause; if it's above 3 BAR, a Pressure Reducing Valve must be installed. Excessive suds from non-commercial detergent can also cause overflow. If this happens, turn off the washer, drain the wash tank, remove as much suds as possible, and run the unit without the overflow pipe for 2-4 minutes before refilling.
  • A
    Alicia RodriguezAug 17, 2025
    What to do if my Jet-tech F-14 will not operate or start?
    • S
      smithlisaAug 17, 2025
      If your dishwasher won't start, first check if the Power ON Indicator Lamp is off. If it is, verify the breaker and all electrical connections. If the Power ON Indicator Lamp is on, make sure that the water supply is turned on.
  • C
    cody86Aug 21, 2025
    What to do if drain time exceeds 2 minutes on my Jet-tech F-14?
    • E
      edward84Aug 21, 2025
      If the drain time exceeds 2 minutes, the drain hose may be kinked, or the drain is blocked. The drain pump may also be blocked and/or defective. Unclog or reposition the hose, and/or replace the drain hose. Unclog or replace the drain pump, as required. If problems persist, call for service.
  • S
    sarahloganAug 25, 2025
    Why does my Jet-tech F-14 Dishwasher fill constantly?
    • C
      Christian GentryAug 25, 2025
      Your dishwasher may be filling constantly because it was turned off for several hours without draining the wash tank. Turn the machine off, remove the overflow pipe, and drain the unit completely. Clean the wash tank and filters, replace all parts, close the door, turn the machine on, and let it fill. Alternatively, the overflow pipe in the wash tank might not be positioned correctly; ensure it drops straight down into the drain receptacle without forcing it. If neither of these solutions works, the water level system may be defective, and you should call for service.
  • K
    Kayla JohnsonAug 27, 2025
    Why does my Jet-tech Dishwasher make a high pitch noise during the wash cycle?
    • S
      Sharon CopelandAug 28, 2025
      A high-pitched noise during the wash cycle usually means there's too much detergent in the wash tank. Reduce the amount of detergent you're using. Drain the unit, refill it, and run a wash cycle. If the squealing continues, call for service.
  • C
    Christine CrawfordAug 31, 2025
    What to do if my Jet-tech Warewasher fills in less than 1 minute?
    • B
      Brooke KleinAug 31, 2025
      If your warewasher fills in less than 1 minute, the incoming water pressure is probably too high (above 3 BAR). If the water pressure is above 3 BAR, a Pressure Reducing Valve must be installed. Also, the water level may be low because the air trap has dirt in it; clean the air trap by pouring water over it.
  • S
    sandrabarrettSep 3, 2025
    Why is my Jet-tech Warewasher filling in more than 3 minutes?
    • C
      Calvin JohnsSep 3, 2025
      If the warewasher is filling in more than 3 minutes, the incoming water pressure may be incorrect. The unit requires a minimum incoming water pressure of 2 BAR. Check that the shut-off valve is fully opened. If the incoming pressure is still low, a pressure-booster pump to increase the water pressure may be required. Additionally, water may be leaking down the drain, so remove and reposition the overflow pipe.
  • M
    Michael FrySep 6, 2025
    What causes spotting or streaks on wares from my Jet-tech F-14?
    • G
      gregory92Sep 6, 2025
      Spotting or streaks on wares usually indicates that the rinse pump needs to be primed or adjusted. Prime and/or adjust the rinse pump.
  • J
    Jennifer BlevinsSep 10, 2025
    Why is the wash pump not operating consistently on my Jet-tech Dishwasher?
    • J
      Jessica MackSep 10, 2025
      Inconsistent wash pump operation can occur if the machine hasn't been leveled. Level the unit using the four adjustable feet. Also, the water level in the wash tank may be too low (below the level of the screens). Turn the machine OFF, remove the overflow pipe, and drain the unit completely. Pour hot water over the air trap, close the door, turn the machine ON, and let it fill. The water level should be even with the screens. If problems persist, call for service.

Summary

Manufacturers Limited Warranty

Technical Data

Installation Guidelines

Removing Panels

F-14 Panel Removal

Instructions for removing rear and front panels of the F-14 model.

F-16 DP Panel Removal

Instructions for removing front bottom and rear panels of the F-16DP model.

F-18 DP Panel Removal

Instructions for removing front bottom and rear panels for electrical access on F-18DP.

F-22 Panel Removal

Instructions for removing front bottom panel for electrical access on F-22.

Electrical System

General Electrical Requirements

Notes on wiring, breakers, grounding, neutral, and licensed electricians.

F-14 Electrical Connection

Details on voltage, amperage, cord, and outlet for the F-14 model.

F-16 DP Electrical Connection

Details on voltage, phase, amperage, and terminal block for F-16DP.

F-18 DP Electrical Connection

Details on voltage, phase, amperage, and terminal block for F-18DP.

F-22 Electrical Connection

Details on voltage, phase, connection, and terminal block for F-22.

Water Supply

General Water Supply Requirements

Notes on temperature, pressure, quality, hook-up, and shut-off valve.

F-14 Water Connection

Details on connection type, pressure, temperature for F-14.

F-16 DP Water Connection

Details on connection type, pressure, temperature for F-16DP.

F-18 DP Water Connection

Details on connection type, pressure, temperature for F-18DP.

F-22 Water Connection

Details on connection type, pressure, temperature for F-22.

Drain Connection

General Drain Connection Guidelines

Notes on gravity drain, hose type, local codes, and drain pumps.

F-14 Drain Connection

Details on drain connection size and hose routing for F-14.

F-16 DP Drain Connection

Details on drain connection size and hose routing for F-16DP.

F-18 DP Drain Connection

Details on drain connection size and hose routing for F-18DP.

F-22 Drain Connection

Details on drain connection size and hose routing for F-22.

Chemicals and Chemical Dispensers

Detergent Pump Adjustment and Priming

Procedures for adjusting and priming the detergent pump.

Rinse Pump Adjustment and Priming

Procedures for adjusting and priming the rinse pump.

Chemical Usage Guidelines

Recommended types of detergent, rinse-aid, and usage warnings.

Control Panel Overview

Basic Steps to Start

Troubleshooting

Unit Fills Constantly

Addresses issues with the dishwasher filling continuously.

Fast Filling Issues

Troubleshooting for warewashers filling in under one minute.

Slow Filling Issues

Troubleshooting for warewashers filling in over three minutes.

Unit Will Not Operate or Start

Steps to resolve issues when the unit fails to start or operate.

High Pitch Noise During Wash

Diagnosing and fixing high pitch noises from the wash pump.

Spotting or Streaks on Wares

Solutions for spotting or streaks appearing on washed wares.

Dishes Not Clean

Troubleshooting steps when dishes are not cleaned properly.

Warewasher Overflows

Addressing issues related to the warewasher overflowing.

Wash Pump Not Operating Consistently

Resolving inconsistent operation of the wash pump.

Drain Time Exceeds 2 Minutes

Troubleshooting long drain times for the unit.

Maintenance Schedule

Daily Maintenance

Routine daily tasks for cleaning and checking the dishwasher.

Weekly Maintenance

Tasks to be performed on a weekly basis for upkeep.

Monthly Maintenance

Tasks to be performed monthly for inspection.

Annual Maintenance

Annual verification by a qualified technician.

Contact and Service Information
