HI TEMP WAREWASHERS
INSTRUCTION,
MAINTENANCE & SERVICE
MANUAL

Questions and Answers

  • B
    Bryce FaulknerNov 25, 2025
    Why is my Jet-tech Washer not washing properly?
    • E
      Elizabeth AndersonNov 25, 2025
      If your Jet-tech Washer isn't washing properly, several factors could be the cause. Start by checking if the wash water is clean; if not, drain, rinse, and refill the tank. Inspect the wash/rinse arm jets for clogs and carefully clean them, ensuring you don't lose the o-rings. Also, make sure the scrap screens are clean. The water level in the wash tank should be just under the opening of the overflow pipe. Other potential issues include a dirty air trap (clean it), a faulty air pressure switch (adjust or replace), or a solenoid valve with dirt or defects (clean filter or replace). Incoming water pressure that's too low (under 25psi) or too high (above 35psi) can also cause problems; adjust accordingly, possibly needing a pressure-booster pump or a pressure-reducing valve. Finally, check f...
  • J
    John GarciaAug 23, 2025
    What to do if my Jet-tech F-22 will not operate or start?
    • J
      Jason WangAug 23, 2025
      If your dishwasher won't start, first check if the Power ON Indicator Lamp is off. If it is, verify the breaker and all electrical connections. If the Power ON Indicator Lamp is on, make sure that the water supply is turned on.
  • D
    Donald JohnsonAug 25, 2025
    What to do if drain time exceeds 2 minutes on my Jet-tech F-22?
    • T
      tylerchristensenAug 25, 2025
      If the drain time exceeds 2 minutes, the drain hose may be kinked, or the drain is blocked. The drain pump may also be blocked and/or defective. Unclog or reposition the hose, and/or replace the drain hose. Unclog or replace the drain pump, as required. If problems persist, call for service.
  • O
    Omar RiveraAug 27, 2025
    What to do if my Jet-tech Washer does not start?
    • G
      Gabrielle DavisAug 28, 2025
      If your Jet-tech Washer isn't starting, begin by checking the power switch to ensure it's properly connected and not defective; replace if necessary. Verify that there's power reaching the machine by checking the breaker and electrical connections. A defective door micro switch, timer, momentary relay, or washing cycle button could also be the issue; consider adjusting or replacing these parts. Look for short circuits in the electrical components or wiring, and check all connections. Also, the solenoid valve may have dirt on it or may be defective; clean filter or replace as required. Additionally, a faulty pressure switch can prevent the washer from starting; adjust or replace it.
  • V
    valeriehahnAug 29, 2025
    How to fix Jet-tech Washer overflow?
    • C
      Charles MeyerAug 29, 2025
      If your Jet-tech Washer is overflowing, the solenoid valve may have dirt in it or may be defective, so replacement may be required. Incorrect incoming water pressure can also cause this issue. Check the drain outlet hose for blockages, and ensure the drain pump isn't blocked or defective, preventing proper drainage. Un-clog or reposition the hose and un-clog or replace the drain pump as needed. Lastly, the overflow itself may be clogged; clean out any residue.
  • R
    Rebekah BennettSep 23, 2025
    Why is the wash pump not operating consistently on my Jet-tech F-22 Dishwasher?
    • H
      hendersonkarenSep 23, 2025
      Inconsistent wash pump operation can occur if the machine hasn't been leveled. Level the unit using the four adjustable feet. Also, the water level in the wash tank may be too low (below the level of the screens). Turn the machine OFF, remove the overflow pipe, and drain the unit completely. Pour hot water over the air trap, close the door, turn the machine ON, and let it fill. The water level should be even with the screens. If problems persist, call for service.
  • J
    jmartinezSep 16, 2025
    Why is my Jet-tech Warewasher filling in more than 3 minutes?
    • A
      Alexander WilliamsSep 17, 2025
      If the warewasher is filling in more than 3 minutes, the incoming water pressure may be incorrect. The unit requires a minimum incoming water pressure of 2 BAR. Check that the shut-off valve is fully opened. If the incoming pressure is still low, a pressure-booster pump to increase the water pressure may be required. Additionally, water may be leaking down the drain, so remove and reposition the overflow pipe.
  • A
    Andrew GriffithSep 18, 2025
    What causes spotting or streaks on wares from my Jet-tech Dishwasher?
    • O
      oconnorhannahSep 18, 2025
      Spotting or streaks on wares usually indicates that the rinse pump needs to be primed or adjusted. Prime and/or adjust the rinse pump.
  • V
    vmedinaSep 8, 2025
    Why is the filling so short in my Jet-tech Washer?
    • P
      perkinsrebekahSep 8, 2025
      If the filling process of your Jet-tech Washer is too short, the air trap may have dirt in it, so clean the air trap. Also, the air pressure switch may be faulty; adjust or replace as required.
  • C
    Cathy RivasSep 5, 2025
    Why is the wash pump not working consistently in my Jet-tech Washer?
    • P
      pvelazquezSep 5, 2025
      If the wash pump in your Jet-tech Washer isn't operating consistently during a wash cycle, the air trap may have dirt in it, so clean the air trap. Also, the air pressure switch may be faulty; adjust or replace it as required. Ensure the machine is leveled. If the water level in the wash tank is too low, adjust the pressure switch or replace it as required.

Summary

WARRANTY INFORMATION

Manufacturers Limited Warranty Terms

Covers warranty period, conditions, and limitations for Jet Tech warewashers.

SERVICE CALL PROCEDURES

WARRANTY CLAIM MANAGEMENT

CONTROL PANEL OVERVIEW

MACHINE OPERATION BASICS

Initial Startup and Water Filling

Guides users through the initial power-on, water fill, and heating processes.

MACHINE OPERATION CONTINUED

ELECTRICAL OPERATION SEQUENCES

Power-On and Heating Stage Logic

Explains the electrical flow from power-on through heating to the ready state.

Wash and Rinse Cycle Electrical Control

Details the electrical components and sequence for wash and rinse cycles.

THERMOSTAT CALIBRATION

Adjusting Wash and Rinse Thermostats

Provides instructions on identifying and adjusting wash and booster thermostats for correct temperatures.

AIR PRESSURE SWITCH CALIBRATION

Air Pressure Switch Functionality

Explains the role of the air pressure switch in water level regulation.

Adjusting the Air Pressure Switch

Details the procedure for adjusting the air pressure switch to set water levels.

RINSE PUMP SYSTEM

Adjusting Rinse Additive Dispensing

Guides on adjusting the amount of rinse additive dispensed by the pump.

LIQUID DETERGENT PUMP

Adjusting Detergent Dispensing Rate

Explains how to adjust the rate at which the liquid detergent pump dispenses.

DRAIN PUMP MANAGEMENT

Drain Pump Operation and Features

Describes the function of the drain pump and models equipped with it.

LIQUID DETERGENT PUMP INSTALLATION

LIQUID DETERGENT PUMP INSTALLATION (cont.)

Adjusting Detergent Injection Timing

Explains how to adjust the timing and duration of detergent injection pulses.

COMPONENT REPLACEMENT

Water Inlet Valve (Solenoid) Replacement

Instructions for replacing the water inlet valve, including specific notes for certain models.

REGULAR MAINTENANCE SCHEDULE

TROUBLESHOOTING GUIDE

Issues with Wash Quality

Addresses problems related to dirty dishes, poor rinsing, and foreign material.

TROUBLESHOOTING GUIDE (cont.)

Machine Start-Up and Operation Failures

Covers issues preventing the machine from starting or operating correctly.
