7
HVBS-8-DMW HVBS-10-DMW HVBS-10-DMWC
Dimensions
Blade wheel diameter 37-1/8 in. (943 mm) 41.73 in. (1060 mm)
Distance table from floor 27-1/2 in. (697 mm) 29 in. (728 mm)
Overall assembled (LxWxH) 54 x 25 x 42 in.
(1381 x 639 x 1060mm)
63 x 27 x 45 in.
(1597.9x676x1144mm)
70 x 35 x 45 in.
(1784 x 878 x 1144mm)
Shipping dimensions (LxWxH) 56.3 x 27.6 x 43.3 in.
(1430 x700 x 1100 mm)
61 x 29.6 x 45.5 in.
(1550 x 750 x 1155 mm)
Weights
Net weight 390 lb. (177 kg) 511 lb. (232 kg)
Shipping weight 454 lb. (206 kg) 582 lb. (264 kg)
Table 1
1
subject to local and national electrical codes.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
L = length, W = width, H = height
n/a = not applicable
The specifications in this manual were current at time of publication, but because of our policy of continuous
improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring
obligations.
