4.0 Specifications for HVBS-DMW series Band Saws
Model number
HVBS-8-DMW HVBS-10-DMW HVBS-10-DMWC
Stock number 424460 424463 424465
Motor and Electricals
Motor type TEFC induction
Horsepower 3/4 HP (0.56 kW) 1 HP (0.75 kW) 1 HP (0.75 kW)
Phase 1
Voltage 115 / 230V (prewired 115V)
Cycle 60 Hz
Listed FLA (full load amps) 9 / 4.5 14 / 7
Motor speed 1720 RPM
Start capacitor 300MFD 125VAC
Power cord SJT 14AWGx3C, 6ft.
Power plug installed 115V
Power transfer Step pulleys with v-belt, to gear reducer box
Gear ratio 1:40 1:50
Recommended circuit size
1
15A 20A (115V), 15A (230V)
Sound emission without load
2
70 dB 75 dB
Coolant pump
n/a n/a 1/8HP 2P 1PH 0.78/0.4A
115/230V
Capacities
Tubing &
Solids
Round
90 deg. 8 in. (200 mm) 10 in. (250 mm)
+/-45 deg. 6 in. (150 mm) 6-1/2 in. (165 mm)
Rectangle
90 deg. 6-1/2 x 8 in.
(165 x 200 mm)
8 x 9 in. (200 x 228 mm)
+45 deg. 7 x 5-1/2 in.
(175 x 137 mm)
8 x 5 in. (200 x 127 mm)
-45 deg. 6 x 5-1/2 in.
(150 x 137 mm)
8 x 5-1/2 in. (200 x 140 mm)
Square
90 deg. 7 x 7 in.
(175 x 175 mm)
8 x 8 in. (200 x 200 mm)
+45 deg. 5-1/2 x 5-1/2 in.
(137 x 137 mm)
5-1/2 x 5-1/2 in. (137 x 137 mm)
-45 deg. 5-1/2 x 5-1/2 in.
(137 x 137 mm)
5 x 5 in. (127 x 127 mm)
Vertical cutting capacity
12 x 8 in.
(305 x 200 mm)
13 x 10 in. (330 x 254 mm)
Bow swivel +/- 45 deg.
Gearbox oil capacity 330 cc (0.07 gal.) 430 cc (0.095 gal.)
Coolant capacity n/a n/a 32 L (7 gal.)
Blade
Blade type and size 6/10T, 3/4 x 0.035 x 102.9 in.
(19 x 0.9 x 2616 mm)
5/8T, 1 x 0.035 x 120 in.
(27 x 0.9 x 3048 mm)
Blade speeds 64, 132, 247 SFPM (19.5, 40, 75 mpm)
Main materials
Bow and stand steel
Blade wheels cast iron
Tires rubber
Pulleys cast iron
Table cast iron and aluminum
