JetCat P70 - Electrical Connection Diagram (2;2)

Electrical connection diagram (2/2)
Connection - diagramm (2/2)
(Verbindungsschema)
ECU bottom-view
(von unten)
Glow-plug
Starter device
Fuel-pump
Outputs are unfused !
max. 12A
Fu
z
z
y
l
o
g
i
c
Microcomputer-Control
Jet-tronic -II- P80
-
To turbine (3 wire cable)
(Zur Turbine 3-adriges Kabel)
Fuelpump
(Kraftstoffpumpe)
