Mounting / fixing of the engine
Dedicated mounting brackets are available for mounting of the engine. Place the brackets around the engine as shown
in the pictures below. Do not over tighten the fixing screws not to deform the engines casing.
P400-PRO Versions
P550-PRO Versions
Best rotation orientation position of
the P550 engine is to rotate the
engine such, that the fuel input is
located around the 4 o´clock position
(looking from front).
