JETI model DUPLEX R Series User Manual

DUPLEX Rx
5
Auto Set: global setup of the receiver to a predefined function. After having selected the desired option,
hold RIGHT and LEFT buttons on JETIBOX simultaneously for 3 seconds.
• Normal: basic setup, mixes off, individual input channels are allocated to relevant outputs (i.e.
input CH1 to output Y1 etc.)
• MixCH1&CH2 Elevon: output channels Y1 & Y2 allocated to mix of inputs CH1 & CH2
• MixCH2&CH4 V-Tail: output channels Y2 a Y4 allocated to mix of inputs CH2 a CH4
Auto Set – Normal = factory default, all received channels CH are passed to relevant outputs Y without
changes, that means the receiver is working like a standard non-programmable receiver.
Channel Set
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
CH1 1,5ms CH1 and CH1 100% +
CH2 1,5ms CH2 and CH2 100% +
CH3 1,5ms CH3 and CH3 100% +
CH4 1,5ms CH4 and CH4 100% +
CH5 1,5ms CH5 and CH5 100% +
CH6 1,5ms CH5 and CH6 100% +
CH7 1,5ms CH7 and CH7 100% +
CH8 1,5ms CH8 and CH8 100% +
Out Pin Set
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Y1 CH1 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Y2 CH2 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Y3 CH3 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Y4 CH4 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Y5 CH5 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Y6 CH6 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Y7 CH7 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Y8 CH8 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Samples of receiver setup:
(changes against default values are marked bold in the tables)
1. V-tail: models with combined tail planes, each plane is controlled by one servo on channels Y2 and Y4,
mix combines movements of rudder CH4 and elevator CH2. Motor on CH3. In case of reverse sense of
the mix change the sign in menu Mix Sign.
Channel Set
Transmitter channel
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
Elevator
CH2 1,5ms CH2 and CH4 100% -
Motor
CH3 1,5ms CH3 and CH3 100% +
Rudder
CH4 1,5ms CH4 and CH2 100% +
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Servo 1
Y2 Mix CH2 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
ESC
Y3 CH3 off off 100% 100% 1,2ms 0s linear 2,0ms 1,0ms
Servo 2
Y4 Mix CH4 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
