JETI model DUPLEX R Series User Manual

DUPLEX Rx
6
2. Elevon: both ailerons are controlled by independent servos on channels Y1 and Y2, move like standard
ailerons on input CH1 (one up, second down) and at the same time like elevators on input CH2 (up/down
simultaneously). In case of reverse sense of the mix change the sign in menu Mix Sign.
Channel Set
Transmitter channel
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
Elevator CH2 1,5ms CH2 and CH1 100% +
Ailerons CH1 1,5ms CH1 and CH2 100% -
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Servo 1 Y2 Mix CH2 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Servo 2 Y1 Mix CH1 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
3. Combination of rudder CH4 and front gear direction control (with deflection reduced to 60% of
rudder deflection), rudder on output Y4 and front gear turn (direction) on output Y7. Gear retraction on
output Y8 (realistic retraction with set Delay, exact servo end stops set - ATV).
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Rudder Y4 CH4 off Off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Gear
direction
Y7 CH4 off Off 60% 60% 1,5ms 0s linear 2,0ms 1,0ms
Gear
retraction
Y8 CH8 off Off 100% 100% 1,82ms 5,0s linear 1,82ms 1,26ms
4. Mix of ailerons Y1 and rudder Y4 (Combi - mix): rudder CH4 moves together with ailerons CH1
(mix); rudder can be still controlled in full range. Useful for scale models.
Channel Set
Transmitter channel
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
Rudder CH4 1,5ms CH4 and CH1 25% +
Ailerons CH1 1,5ms CH1 and CH1 100% +
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Rudder Y4 Mix CH4 off off 200% 200% 1,5ms 0s linear 2,0ms 1,0ms
Ailerons Y1 CH1 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
5. Mix of elevator CH2 and flaps CH6: when flaps Y6 move, also elevator Y2 moves in opposite
direction.
Channel Set
Transmitter channel
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
Flaps CH6 1,5ms CH6 and CH6 100% +
Elevator CH2 1,5ms CH2 and CH6 25% -
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Elevator
Y2 Mix CH2 off off 200% 200% 1,5ms 0s linear 2,0ms 1,0ms
Flaps
Y6 CH6 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
