JETI model DUPLEX R Series User Manual

DUPLEX Rx
7
6. Flaperon: mixes aileron CH1 and flaps (or airbrakes) CH6. Each aileron is controlled by independent
servo Y1 and Y2, ailerons work normally depending on stick position. At the same time, ailerons may
move up (airbrakes) or down (flaps) – depending on flap control.
Channel Set
Transmitter channel
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
Flaps CH6 1,5ms CH6 and CH1 100% +
Ailerons CH1 1,5ms CH1 and CH6 100% -
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Servo 1 Y2 Mix CH6 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Servo 2 Y1 Mix CH1 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
7. Mix flaps-elevator: elevator CH2 automatically balances diving moment caused by move of flaps CH6.
At the same time, there is a mix flaps-ailerons (ailerons act as flaps).
Channel Set
Transmitter channel
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
Ailerons CH1 1,5ms CH1 and CH6 100% -
Elevator CH2 1,5ms CH2 and CH6 25% +
Flaps CH6 1,5ms CH6 and CH1 100% +
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Aileron 1 Y1 Mix CH1 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Elevator Y2 Mix CH2 off off 200% 200% 1,5ms 0s linear 2,0ms 1,0ms
Aileron 2 Y6 Mix CH6 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
8. Mix ailerons-flaps: both flaps and ailerons are on the wings. CH1 controls ailerons (Y1 and Y5), CH6
controls flaps (Y6 and Y7). Mixes ailerons so that they work also like flaps..
Channel Set
Transmitter channel
SetInputChannel CHx Set Center Mix CHx and CHy
Mix
Relation
Mix Sign
Ailerons CH1 1,5ms CH1 and CH6 100% +
Flaps CH6 1,5ms CH6 and CH1 100% -
Out Pin Set
Function
Set Output
Pin
SetInChannel Reverse A Reverse B Gain A Gain B Fail Save Delay Curve
ATV
HighLimit
ATV
LowLimit
Aileron 1 Y1 Mix CH1 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Aileron 2 Y5 Mix CH6 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Flap 1 Y6 CH6 off off 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
Flap 2 Y7 CH6 on on 100% 100% 1,5ms 0s linear 2,0ms 1,0ms
