computer radio control system
Every receiver is able to transmit the actual voltage supplied to the
on-board system (i. e. receiver voltage) without the need to connect
any additional external sensors. If you want to take advantage of
extended telemetry, connect a telemetry sensor to the Ext. input of
the receiver. If you want to operate several telemetry sensors
simultaneously with one receiver, you must use one or more of the
Expander EX devices, which , when connected to the Ext. receiver
input, gives you multiple inputs for telemetry sensors.
There are two ways to use JETI telemetry. The EX telemetry is
available to owners of the JETI DC/DS transmitters or the
JETIBOX profi. The 1st Generation Telemetry can be used by
owners of the TU, TG, TF etc. transmitter modules.
4.1 EX Telemetry
This telemetry data is displayed according to user selections in the
DC/DS transmitters and the JETIBOX profi. You will find more
details in actual instruction manuals of the given Duplex EX
equipment.
4.2 - 1st Generation
Connect the JETIBOX to the transmitter module. Switch on the
transmitter and connect the receiver voltage supply (see chapter
„Voltage supply“). The Tx heading appears in the JETIBOX display
and by pressing the push-button R (right button) twice, select the
Mx menu. By pressing the push-button D (down) you will enter the
telemetry sensor or expander menu. You may leave the telemetry
sensor menu by pressing the push-button U(up) slightly longer.
4 Real time telemetry
EN
8
®
User ManualUser ManualUser Manual
EN
Receivers REXReceivers REX
FW 1.00FW 1.00
Receivers REX
FW 1.00
COMPLEX RADIO CONTROL SYSTEM
