computer radio control system
Rx mode - the working mode of the receiver. Possible choices:
Normal
ź bidirectional communication between receiver and
transmitter
ź select this setup for the model‘s main receiver
ź use the same setup if you use only one receiver in your model
(in case you are using only one Duplex receiver for remote
control)
Clone
ź unidirectional communication
ź if you use several Duplex receivers in the model, for instance in
connection with one transmitter module, then you should
operate one of the receivers in „Normal“ mode and the others
in „clone“ mode
ź the receiver operating in „Normal“ mode is considered to be
the main receiver. One of the transmitter modules is able to
control only one receiver in „Normal“ mode
ź if you want to operate several receivers with only one
transmitter module, you should operate them in „clone“
mode
If you switch the receiver to „clone“ mode, further wireless setup
communication becomes impossible because the receiver is now
communicating only unidirectionally. In order to change the mode
or setup, you have to connect the JETIBOX to the receiver and make
the desired change or switch the receiver back to„Normal“ mode:
1. Insert BIND PLUG into the receiver socket labeled Ext.
2. Switch on receiver
3. Switch on transmitter
4. Execute the desired setup changes, see „Receiver setup“
EN
