Jetson Adventure 2.0 2022 - Getting Started; Installing the Handlebar

15
1. Getting Started
1.1 Installing the Handlebar
YOU WILL NEED THE 4MM (MEDIUM-LENGTH) ALLEN KEY.
1. LOOSEN AND REMOVE THE 4 SCREWS ON THE HANDLEBAR CLAMP BY TURNING THEM COUNTERCLOCKWISE WITH
4MM ALLEN KEY.
2. REMOVE THE CLAMP COVER AND SET IT ASIDE WITH THE 4 SCREWS.
IMPORTANT: THE DIRECTIONS GIVEN IN THIS MANUALRIGHT, LEFT, FRONT, REARARE ORIENTED AS THE RIDER WOULD SEE
THEM WHEN SITTING ON THE BICYCLE. THE “RIGHT SIDE” OF THE BIKE, FOR EXAMPLE, IS THE SIDE WHERE THE RIDER’S RIGHT
HAND AND RIGHT FOOT WILL BE.
SCREWS
CLAMP COVER
