6MM ALLEN KEY
FRONT FORK
CAP BOLT
8. CHECK THAT THE HANDLEBAR AND FRONT FORK ARE ALIGNED, SUCH THAT WHEN THE WHEEL IS POINTED FORWARD
AND THE HANDLEBAR IS STRAIGHT ACROSS THE BIKE. IF NECESSARY, MAKE ROTATIONAL ADJUSTMENTS ON EITHER THE
HANDLEBAR OR THE FORK UNTIL BOTH PIECES ARE STRAIGHT AND ALIGNED.
9. WITHOUT EXPOSING THE "MINIMUM INSERTION" MARK, BRING THE HANDLEBAR UP TO THE DESIRED HEIGHT.
HOLD IT IN POSITION WHILE YOU SECURE IT IN PLACE BY TURNING THE CAP BOLT CLOCKWISE WITH THE ALLEN KEY
UNTIL IT IS TIGHT.
10. CHECK THAT THE HANDLEBAR IS SECURE AND THAT THE WHEEL TURNS LEFT OR RIGHT IN ACCORDANCE WITH THE
ROTATION OF THE HANDLEBAR.
