1.10 Securing the Bell
YOU WILL NEED THE PHILLIPS-HEAD SCREWDRIVER
1. LOOSEN BUT DO NOT REMOVE THE SCREW ON THE BELL CLAMP BY TURNING IT COUNTERCLOCKWISE FOR 1 2
ROTATIONS WITH THE SCREWDRIVER.
2. ROTATE THE BELL AROUND THE HANDLEBAR UNTIL IT IS IN A POSITION WHERE THE BELL TAB CAN EASILY BE REACHED BY
THE RIDER’S RIGHTHAND THUMB WHEN HOLDING ONTO THE HANDLEBAR.
3. TIGHTEN THE SCREW BY TURNING IT CLOCKWISE WITH THE SCREWDRIVER TO SECURE THE BELL CLAMP IN PLACE.
SCREW
BELL TAB
BELL
SCREWDRIVER
