Jetson Zephyr User Manual

31
1.8 Installing the Seat
1. PULL OPEN THE LATCH ON THE SEAT CLAMP.
2. LOCATE THE "MINIMUM INSERTION" MARK ENGRAVED NEAR THE BOTTOM OF THE SEAT POST. LOWER THE SEAT POST
THROUGH THE CLAMP AND INTO THE SEAT TUBE. IF THE CLAMP OPENING IS TOO NARROW TO RECEIVE THE POST, YOU
CAN WIDEN IT BY TURNING THE KNOB COUNTERCLOCKWISE WHILE HOLDING THE LATCH STEADY.
3. SLIDE THE SEAT POST DOWN AT LEAST UNTIL THE MINIMUM INSERTION MARK IS NO LONGER VISIBLE. ADJUST THE SEAT
HEIGHT TO RIDER’S COMFORT.
IMPORTANT: WHEN A RIDER IS SITTING ON THE BIKE AND HAS A FOOT ON THE PEDAL AT THE LOWEST PEDAL ROTATION
POINT, THERE SHOULD BE A SMALL BEND IN THE KNEE. LEGS SHOULD NEVER BE FULLY EXTENDED DURING PEDALING.
"MINIMUM
INSERTION" MARK
SEAT
SEAT POST
CLAMP LATCH
SEAT CLAMP
CLAMP KNOB
(opposite side- not shown)
