3. POSITION THE FENDER BEHIND THE FRONT FORK SUCH THAT
THE FOLLOWING CONDITIONS ARE MET:
· THE HOLE IN THE FENDER TAB IS ALIGNED WITH THE HOLE
ON THE BACKSIDE OF THE FORK FROM WHICH YOU JUST
REMOVED THE HARDWARE.
· THE CURVE IN THE FENDER ALIGNS WITH THE CURVE OF THE
WHEEL.
· THE BACK OF THE FENDER, TO WHICH THE FENDER BRACES
ARE ATTACHED, IS AT THE REAR OF THE WHEEL.
· THERE IS ONE FENDER BRACE ON EACH SIDE OF THE WHEEL.
· THE FENDER BRACES ARE ANGLED TOWARDS THE FRONT OF
THE BIKE.
4. SLIDE THE BOLT THROUGH THE HOLE ON THE FRONT SIDE OF
THE FORK, AND THEN THROUGH THE HOLE IN THE FENDER TAB.
SLIDE THE WASHER ONTO THE END OF THE BOLT, AND THEN
REPLACE THE NUT BY FINGERTURNING IT CLOCKWISE ONTO
THE END OF THE BOLT. DO NOT COMPLETELY TIGHTEN THE BOLT
AND NUT.
BOLT
WASHER
10MM WRENCH
NUT
FRONT FENDER
FENDER BRACE
PHILLIPSHEAD SCREWDRIVER
