WASHER
4. SLIDE THE WASHERS BACK ONTO THE STEMS OF THE REMOVED SCREWS.
5. IN THE FOLLOWING ORDER, INSERT EACH SCREW THROUGH THE
4 ALIGNED SETS OF HOLES. FASTEN BUT DO NOT FULLY TIGHTEN
THEM INTO THE FRAME BY TURNING THEM CLOCKWISE WITH THE
SCREWDRIVER:
A. THE SCREW AT THE FRONT OF THE CARGO RACK ON THE LEFT SIDE.
B. THE SCREW ABOVE THE AXLE NUT ON THE RIGHT SIDE.
C. THE SCREW AT THE FRONT OF THE CARGO RACK ON THE RIGHT SIDE.
D. THE SCREW ABOVE THE AXLE NUT ON THE RIGHT SIDE.
CARGO RACK
REFLECTOR
SCREWDRIVER
SCREW
5D
5A
5C
5B
